Denon AVR-S750H 7.2ch 4K AV Receiver

7.2 channel full 4K Ultra HD AV receiver with 165W per channel (6 ohms, 1 kHz, THD 10%, 1ch driven), Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X™, DTS Virtual:X®, new eARC support, HDMI (6 inputs/ 1 output), Wi-Fi, Bluetooth and HEOS built-in wireless multi-room music streaming and voice control compatibility.

UPGRADE TO IMMERSIVE HOME THEATER

The 7.2 channel AVR-S750H supports immersive audio formats Dolby Atmos®, Dolby Atmos Height Virtualization, DTS:X™ and DTS Virtual:X®. Features an advanced
HDMI section (6 inputs/1 output) and the latest video technologies including Dolby Vision™, HDR10, HLG and eARC support. Play your MP3, WAV, FLAC, ALAC and
DSD (2.8/5.6MHz) files via the front-panel USB, or stream Spotify®, Pandora®, Tidal and more with HEOS wireless multi-room music streaming technology.

HIGHLIGHTS YOUR BENEFITS

High-performance discrete 7-channel amplifier Delivers maximum performance and 165W per channel
Dolby Atmos and DTS:X Enjoy an immersive, three-dimensional audio experience

Dolby Atmos Height Virtualization Technology and DTS Virtual:X Experience three-dimensional audio without the need for height speakers
6 HDMI inputs with full HDCP 2.3 support, 1 output Connect up to six of your favorite media devices with full 4K support, 4:4:4 color
resolution and BT.2020

The latest picture/video technology available 4K Ultra HD/60 Hz full-rate pass through, HDR10, Dolby Vision compatibility and
Hybrid Log-Gamma (HLG)
Award-winning Denon Setup Assistant Graphical user interface for an easy and intuitive setup experienceEffortless voice control Works with Amazon Alexa, Google Assistant or Apple Siri for hands-free control
of your music
HEOS Built-in for multi-room music streaming Wirelessly stream your favorite music services including Spotify, Pandora and more.

High-Performance Discrete 7-Channel Amplifier

Featuring discrete high-current power amplifiers on all
channels, the AVR-S750H delivers 165W per channel (6 ohms,
1 kHz, THD 10%, 1ch driven). With low impedance driver
capability, it offers operational stability with a wide range of
speakers for balanced, quality sound. Plus, auto Eco Mode
adjusts power output to speakers based on volume level and
on-screen eco meter, providing power consumption reduction
in real-time.

Advanced HDMI Video Section with eARC SupportEnjoy your favorite movies, shows and games with the best
picture quality available.

The AVR-S750H features six HDMI inputs and one output — including one input on the front panel — that support full 4K Ultra HD, HDR10 (High Dynamic Range),BT.2020, Wide Color Gamut and 4:4:4 Pure Color sub-sampling. Dolby Vision compatibility and HLG (Hybrid Log-Gamma) provide
exceptional brightness, contrast and color. HDCP 2.3 processing
is available on all HDMI ports.

Built-in Bluetooth and Wi-Fi Connectivity

With Bluetooth and Wi-Fi wireless streaming connectivity, the Denon
AVR-S750H is equipped with an advanced dual antenna transceiver
system for robust streaming even in congested urban environments.
Enjoy listening to your favorite audio content wirelessly from your
smart devices.

Audyssey Suite of EQ Calibration Technology
Professional home theater audio tuning at your fingertips.

The latest Denon audio/video products use the Audyssey
suite of EQ software for simple, accurate set-up and calibration.
With the supplied measuring microphone, Audyssey measures
all the speakers in your home theater, and tunes the AV receiver to
provide the smoothest, most optimal overall listening experience
for your room. Audyssey Dynamic Volume and Audyssey
Dynamic EQ smooth out startling jumps in volume (such as TV
commercials), letting you listen at lower levels and still enjoy
clear dialogue, music, sound effects and precise tonal tailoring.

For the enthusiast, the Audyssey MultEQ Editor app lets you view
speaker detection data to check the before-and-after results of
the Audyssey calibration, making it easy to optimize individual
room acoustics to personal taste.

Dolby Atmos, Dolby Atmos Height Virtualization Technology,
DTS:X and DTS Virtual:X

Immerse yourself in multi-dimensional audio with Dolby Atmos,
DTS:X, Dolby Atmos Height Virtualization Technology and DTS
Virtual:X. Set up Dolby Atmos with a 5.1.2 surround sound speaker
system using Dolby Atmos elevation speakers or dedicated
overhead speakers, for the ultimate home theater experience.

DTS:X™ immersive audio places sound where it would occur
naturally in space, creating a lifelike, multi-dimensional audio
experience in the home. The improved immersion and heightened
realism draw you into the world of your favorite movies. The
included DTS Neural:X™ gives your movies, games and music
a realism unmatched by traditional 5.1 surround sound. Dolby
Atmos Height Virtualization Technology and DTS Virtual:X provides
immersive audio without height channels, creating virtual height
effects in a 5.2, 7.2 or 2.2 speaker arrangement.

Works with Amazon Alexa
Control the AVR-S750H hands-free with Amazon Alexa and your
voice. Adjust the volume, skip to the next track, switch inputs for
your different media players and more — “Just Ask.” Download
the free HEOS Home Entertainment Skill to enable Amazon Alexa
voice commands for your AVR-S750H. Requires Alexa app and
Amazon Echo, Dot or equivalent.

Easy Setup Experience

The included AVR-S750H Quick Start Guide provides simple,
clear instructions for how to get started. Once you connect your
TV to the AVR-S750H via HDMI, the exclusive Denon Setup Assistant
appears on your TV screen to walk you through setup, step by step.
The AVR-S750H automatically renames input source per HDMI info,
and quick select offers one-push buttons for all zones. Color-coded
speaker connections are laid out horizontally, making organizing
and connecting speaker wires simple.

Smart TV Connectivity

Control the Denon AVR-S750H with your Smart TV remote via the
HDMI CEC functionality associated with your Smart TV. Simply set
“HDMI Control” to ON in your receiver, then set “Smart Menu” to
ON and begin controlling the AVR-S750H with your TV remote.
The Smart Menu home screen provides you quick access to source
and surround mode selections, the AV receiver setup menu and four
Smart Selects.

Quick Selects for User-Friendly Audio Tuning

The Denon AVR-S750H front panel features four Quick Select
buttons that store your preferred audio settings for each source.
Switch between TV audio, Blu-ray, media players and more,
and the AVR-S750H adjusts the EQ settings to your preferences
for that media source. Use the buttons on the front panel or opt
for the same Quick Selects on the AV receiver remote control
for faster control. Now allows for one-push all zone stereo
mode via Quick Select.

HEOS Built-in for Wireless Music Streaming

Enjoy your favorite music in any room of your home wirelessly
with HEOS built-in technology. Play the same song in every room
or select a different song for each connected room — the choice
is yours. HEOS works with Amazon Alexa and Google Assistant,
providing effortless voice control.

Front USB Port for High-Resolution Audio

Discover the incredible fidelity of high-resolution audio tracks
with the ability to decode up to 24-bit/192-kHz ALAC, FLAC
and WAV lossless files as well as DSD 2.8MHz and 5.6MHz
tracks (the audiophile format of SACD) via the front panel USB
port and network sources. Or, listen to other popular file types
such as MP3 and MPEG-H. Whether you want to listen to your
latest download or soak in the fidelity of audiophile-quality
FLAC recordings, you have quick access to your favorite songs.

Technical information
Number of
Power Amps
7
Power Output 75W per channel
(8ohms, 20Hz-20kHz, THD 0.08%,
2 ch driven)
110W per channel
(6 ohms, 1 kHz, THD 0.7%, 2 ch drive)
165W per channel
(6 ohms, 1 kHz, THD 10%, 1 ch driven)
Speaker Impedance 4 - 16Ω/ohms
Preamplifier Section
Input sensitivity/
impedance
200 mV
Frequency response 10 Hz - 100 kHz — +1, –3 dB
(Direct mode)

S/N Ratio 98 dB (IHF-A weighted, Direct mode)
FM Section
Tuning frequency range 87.5 - 107.9 MHz
AM Section
Tuning frequency range 520 kHz – 1710 kHz
General
Power supply AC 120 V, 60 Hz
Power consumption 400W (Standby 0.1 W, CEC standby
0.5W)
Power consumption
No-sound
29W (ECO Mode On)
39W (ECO Mode Off)
Dimensions (W x H x D) 17.1” x 13.3” x 6” in
Weight 19 lbs

Ports
IN HDMI (Front 1) x 5 + 1
Component (video) -
Composite (video) x 2
Phono x 1
Analog Audio x 2
Digital Optical x 1
USB (front) x 1
OUT HDMI Monitor x 1
Component (video) -
Audio Pre-out (SW) 2 ch
Phones x 1
