Onkyo TX-RZ720 7.2-Channel Network A/V Receiver & Onkyo BD-SP353 Bluray Player - Black

Package includes -

Onkyo TX-RZ720 7.2-Channel Network A/V Receiver
Onkyo BD-SP353 Bluray Player

Onkyo TX-RZ720 7.2-Channel Network A/V Receiver

Key Features

THX® Certified Select™ Reference Sound
Unleash Dolby Atmos® or DTS:X™ Home Cinema
Onkyo Controller Supports Next Generation Network Audio
Chromecast built-in*, DTS Play-Fi®*, FlareConnect™
Wi-Fi®, AirPlay, Spotify®, and Bluetooth®
Supports HDR10, HLG, Dolby Vision™, BT.2020, 4K/60 Hz, and HDCP 2.2

7.2-Channel Network A/V Receiver

Invest in THX® Certified Select™ Theater Performance

The TX-RZ720 offers THX Certified Select cinema-reference sound and state-of-the-art features for breathtaking entertainment in the living room and beyond. Expect smooth and powerful 5 Hz–100 kHz reproduction with thrilling dynamics and exquisite detail rendition, whether you’re driving all channels with object-audio soundtracks or streaming music via Chromecast built-in*, AirPlay, or DTS Play-Fi®*. Tap your touchscreen to share music to compatible speakers and components over FlareConnect™*. HDMI® now supports pass-through of HDR features including HLG (Hybrid Log-Gamma), Dolby Vision™, and BT.2020 to the latest displays, while a suite of connections integrate the receiver into home automation systems. * Enabled with a firmware update.

HIGHLIGHTS

175 W per Channel of THX® Certified Select™ Reference Sound
Supports 5.2.2-Channel Dolby Atmos® and DTS:X® Playback
Dynamic Audio Amplification with 5 Hz–100 kHz Frequency Response
7 HDMI® Inputs (1 Front*1) / Main Out/Zone 2 Out Supporting Dolby Vision™, HDR10, HLG, and 4K/60p Pass-through and HDCP 2.2
384 kHz/32-bit DAC and VLSC™ Filtering for Superior Clarity
Chromecast built-in*2, DTS Play-Fi®*2, and FlareConnect™*2 Multi-room Audio
5 GHz/2.4 GHz Wi-Fi®, AirPlay, Spotify®, TIDAL, Deezer, TuneIn*3

ADVANCED FEATURES

THX Certified Select for Cinema-Reference Volume and Sound Quality
HDMI Terminals Supporting Dolby Vision, HDR10, HLG, BT.2020, 4K/60 Hz Pass-through, and HDCP 2.2
Zone 2 HDMI (4K/60 Hz/HDCP 2.2) for Distributed Video
Supports 5.2.2-Channel Dolby Atmos Playback and Dolby Surround Upmixing
DTS:X Object-based Audio Reproduction and DTS Neural:X™ Upmixing for Legacy Soundtracks
AccuEQ Room Acoustic Calibration with AccuReflex Phase Alignment for Dolby Atmos-enabled Speakers
Ready for Onkyo Controller App Integrated Multi-room Intuitive Operation*4
5 GHz/2.4 GHz Wi-Fi for Stable Network Connection
Features Chromecast built-in Wireless Audio Streaming Platform
Supports DTS Play-Fi Multi-room Audio
AirPlay Audio Streaming from iTunes and iPad, iPhone, and iPod touch
Supports Hi-Res Audio Including DSD 2.8 MHz/5.6 MHz*5, 192 kHz/24-bit FLAC, WAV, AIFF, and ALAC, and Dolby® TrueHD*6
Supports Spotify, TIDAL, TuneIn, and Deezer Services
FlareConnect Multi-room Audio Distribution to Compatible Components and Speakers
Powered Zone 2 Speaker Outputs and Zone 2 Pre-/Line Output with Dedicated DAC Supporting Network, S/PDIF, HDMI, and Analog Audio
Bluetooth® Wireless Technology for Mobiles, Laptops, and PCs (Version 4.1 + LE, Profile: A2DP v1.2, AVRCP v1.3)
Supports Front L/R Channel Bi-Amping in 5.2-Ch Speaker Layout
Advanced Music Optimizer Improves Compressed Digital Audio Quality, Including Bluetooth Audio
480i De-interlacing (480i to 480p) for Legacy Video Formats

AMPLIFIER FEATURES

175 W/Ch (6 Ω, 1 kHz, 1% THD, 1 Channel Driven, IEC)
Dynamic Audio Amplification System with 5 Hz–100 kHz Frequency Response
High-Current Power to Drive Large Speakers with 4-Ohm Resistance
H.C.P.S. (High Current Power Supply) EI Transformer
VLSC™ (Vector Linear Shaping Circuitry) High-frequency Noise-filtering Technology (Front L/R Channels)
Non-Phase-Shift Amplification Circuitry for Clarity and Detail
Discrete Output Stage Circuitry for Low Distortion
Optimum Gain Volume Circuitry

PROCESSING FEATURES

Dolby Atmos and DTS:X Reproduction (5.2.2 Channels)
HDMI Support for 4K/60 Hz, HDR10, HLG, Dolby Vision, 3D, Audio Return Channel, DeepColor™, x.v.Color™, LipSync, Dolby Atmos, Dolby TrueHD, DTS:X, DTS-HD Master Audio™, DSD, DVD-Audio, Super Audio CD (SACD), Multichannel PCM, and CEC
AKM (AK4458) 384 kHz/32-bit Multichannel DAC
PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology for S/PDIF Audio
32-bit Digital Signal Processing
THX Listening Modes for Movies, Music, and Games
DSP Modes for Gaming: Rock, Sports, Action, and RPG
Theater-Dimensional Virtual Surround Function
Direct Mode for Audio Reproduction Close to Original Source Quality
Front L/R Tone Controls (Bass/Treble) and Independent Zone 2 Tone/Balance Controls

CONNECTION FEATURES

7 HDMI Inputs (6 Rear, 1 Front) and 2 Outputs (Main Out, Zone 2 Out)
Powered USB Port (5 V, 1 A) for Audio Playback
2 Composite Video Inputs
2 Component Video Inputs
3 Digital Audio Inputs (2 Optical and 1 Coaxial)
6 Analog Audio Inputs (Coaxial), 1 Stereo 3.5 mm Analog Input (Front)
Phono Input (MM) and Equalizer for Turntable
2 Subwoofer Pre-Outs
LAN Input with IP Control Support for Home Automation Systems and Setup via a Connected PC
RS-232 Serial Input for External Control Commands
12 V Trigger Out (Main, 100 mA) for External Component Control Integration
IR Input for Remote Control
6.35 mm Headphone Jack (Front)
Speaker Posts with Screw Knobs
3.5 mm Speaker Setup Mic Input and Microphone

OTHER FEATURES

Crossover Adjustment for Each Channel (40/50/60/70/80/90/100/120/150/180/200 Hz)
A/V Sync Control (Up to 500 ms in 5 ms Steps at 48 kHz)
Graphical User Interface with Overlaid On-Screen Display (OSD) via HDMI
Quick Setup Guide via GUI and Easy Connection Diagram on Rear Panel
Large Input Selector Buttons and Front Panel Tone/Balance Controls
Economical HDMI Pass-through and Network Standby Functions
IP Control Support for Home Automation Systems
3-Mode Display Dimmer (Normal/Dim/Dimmer)
40 FM/AM Random Presets
Rack-mounting Kit (Optional)
Full-sized Simple Remote Control

Onkyo BD-SP353 Bluray Player

Affordable Blu-ray Disc Player with Hi-Res Audio Playback

The sleek, minimalist lines of the BD-SP353 pack enough playback prowess to enliven any entertainment space. Partnered with one of Onkyo’s high-value home cinema systems, the BD-SP353 brings you the phenomenal detail and realism of Blu-ray. But that’s not the only source it handles. Along with DVD and CD playback, the BD-SP353 features an Ethernet port which opens up the interactive, content-rich world of BD-Live. Connectivity is also a highlight. The USB port on the BD-SP353 even allows you to play 192 kHz/24-bit Hi-Res Audio formats such as FLAC and WAV. Also it lets you play media from a variety of storage devices. Content encoded in HD formats such as AVCHD and DivX Plus™ HD is handled with ease, and all standard-definition video can be upscaled via HDMI® to widescreen 1080p. As well as handling Blu-ray video, the HDMI output also supports lossless audio from Dolby® and DTS™. So if it’s a versatile and affordable playback solution you seek, look no further than the BD-SP353.

ADVANCED FEATURES

HDMI® Output Supports 1080p, Deep Color™, x.v.Color™ and CEC
Dolby® TrueHD and Dolby® Digital Plus Decoding
Supports DTS-HD Master Audio™ Essential and DTS-HD High Resolution Audio™
DVD Upscaling to 1080p
Plays AVCHD*, DivX Plus™ HD (MKV), MP3, and JPEG Formats
1080/24p Video Output for Full HD Movies on Blu-ray Discs
BD-Live Functionality for Interactive Content
USB Port for Hi-Res Audio Playback (192 kHz/24-bit WAV, FLAC)

*Encoded on DVD-R/RW only.
AUDIO & VIDEO FEATURES

Plays BD-Video (BD-ROM, BD-R, BD-R DL, BD-RE, DE-RE DL, BD-R LTH)
Plays DVD-Video (DVD Video, DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD+RW, DVD+R DL, AVCHD Disc)
Plays Audio CDs and USB Audio Playback (CD-DA, CD-R, CD-RW, MP3, WMA, AAC, WAV, FLAC)
Digital Audio Output (Optical)
2-Channel Analog Audio Output

OTHER FEATURES

BONUSVIEW™ Compatible
Quick (x1.5) and Slow (x0.8) View with Audio Playback
Quick Start Function
Continue Mode to Resume Even After Powering Off the Player
Short Skip / Replay
On-Screen Display with Multiple Languages
(English, German, Hungarian, Czech, Slovak, Polish,
Slovene, Turkish, French, Italian, and Spanish)
Auto Power Down
Firmware Updates (via USB)

HDMI Output Supports 1080p, Deep Color, x.v.Color and CEC
Dolby TrueHD and Dolby Digital Plus Decoding
Supports DTS-HD Master Audio Essential and DTS-HD High Resolution Audio
DVD Upscaling to 1080p
Plays AVCHD, DivX Plus HD (MKV), MP3, and JPEG Formats
1080/24p Video Output for Full HD Movies on Blu-ray Discs
BD-Live Functionality for Interactive Content
USB Port for Hi-Res Audio Playback (192 kHz/24-bit WAV, FLAC)

The sleek, minimalist lines of the BD-SP353 pack enough playback prowess to enliven any entertainment space.
Partnered with one of Onkyo's high-value home cinema systems, the BD-SP353 brings you the phenomenal detail and realism of Blu-ray.
But that's not the only source it handles.
Along with DVD and CD playback, the BD-SP353 features an Ethernet port which opens up the interactive, content-rich world of BD-Live.
Connectivity is also a highlight. The USB port on the BD-SP353 even allows you to play 192 kHz/24-bit Hi-Res Audio formats such as FLAC and WAV.
Also it lets you play media from a variety of storage devices.
Content encoded in HD formats such as AVCHD and DivX Plus HD is handled with ease, and all standard-definition video can be upscaled via HDMI to widescreen 1080p.
As well as handling Blu-ray video, the HDMI output also supports lossless audio from Dolby and DTS.
So if it's a versatile and affordable playback solution you seek, look no further than the BD-SP353.

High-Definition Surround Sound from Dolby TrueHD and DTS-HD Master Audio
The BD-SP353's onboard decoders bring you the lossless, studio-master quality of Dolby TrueHD and DTS-HD Master Audio Essential for Blu-ray Disc.
The player outputs these formats in pure bitstream form via HDMI, meaning nothing is lost from the original recording.
If you don't have an HDMI-compatible receiver, you can still enjoy playback of standard Dolby Digital and DTS 5.1-channel content via the onboard optical digital output.

BD-Live Offers a More Interactive Experience
The BD-SP353's BD-Live capabilities let you connect directly to the internet and access a variety of up-to-date content, such as movie previews, games, and live peer-to-peer interactions.
The BD-Live specification also includes BonusView features, such as picture-in-picture.
This function lets you view a small video in the corner of the screen while the main feature plays in the background.

Full High-Definition 1080p Video and Compatibility with AVCHD and DivX Plus HD
Blu-ray Disc delivers the most vivid and detailed video images ever seen in home theater.
A disc played back on the BD-SP353 can be output in full high-definition 1080p at 24 frames per second-the native frame rate for movies.
Meanwhile, the BD-SP353 offers compatibility with the increasingly popular DivX Plus HD (MKV) and AVCHD formats, which employ high-compression video codecs.
Now you can enjoy big-screen playback of your high-definition movies and video clips recorded on a compatible camcorder.

Continue Mode Gets You Back to Where You Were Watching
Continue key on the remote allows you to save where you left off last night.
It lets you continue your entertainment with a snap.

1080p Upscaling Sharpens Your DVD Picture
1080p upscaling improves your standard-def DVD pictures to Full HD, giving your collection a new lease on life.

Specifications:
- Video Section
- Signal System PAL / NTSC
- HDMI Output 480p/576p, 720p, 1080i, 1080p, 1080p/24 fps

General
- Power Supply: AC 110-240 V, 50/60 Hz
- Power Consumption: 13 W
- Quick Standby Power Consumption: 1 W
- Standby Power Consumption: 0.3 W
- Dimensions (W x H x D): 435mm x 58mm x 249mm
- Weight: 2.0 kg

CARTON
- Dimensions (W x H x D): 503mm x 122mm x 342mm
- Weight: 3.3kg
