Mission QX-5 MKII Floorstanding Speakers - pair - Black

Mission QX-5 MKII Floorstanding Speakers - pair - Black


The QX-5 MKII is a 3-way loudspeaker with a 12″ (300mm) bass driver, a 6.5″ (165mm) midrange driver and a ring dome treble unit.

As per all Mission speaker concepts, the process of listening, listening and more listening is the key to improvement. With the added benefit of modern speaker design tools, such as computer-aided optimisation technology, crossover modeling, and laser interferometry, Mission engineers also spent much time fine tuning the crossovers, components, materials, and construction.

Much like the now-established and equally class-leading Mission LX MKII series, the QX MKII series takes an already phenomenal loudspeaker solution but refines it, optimises it, and brings even more vibrancy, finesse, and class, through a process of evolution, not revolution.

General Description 3-way Floorstanding Speaker

Enclosure Type Bass Reflex
Transducer Complement 3-way
Bass Driver 12" (300mm) Cone Long-throw x1
Midrange Driver 6.5" (165mm) Long Fiber Composite Cone x2
Treble Driver 1.5"(38mm) Textile Ring Dome
AV Shield No
Sensitivity (2.0V @ 1m) 90dB
Recommended Amplifier Power 30-200W
Peak SPL 96dB
Nominal Impedance 4 Ω (compatible 8Ω)
Minimum Impedance 3.5Ω
Frequency Response (+/-3dB) 32Hz ~ 24kHz
Bass Extension (-6dB) 27Hz
Crossover Frequency 180Hz,1.8kHz
Cabinet Volume (in litres) 16L/48L
Height (on plinth) (1100+20)mm
Width 220mm
Depth (with terminals) (400+10)mm
Carton Size 535 x 350 x 1250mm
Net Weight 34kg/pcs
