Rotel RMB-1587MKII Multi-Channel Power Amplifier - Black

Rotel RMB-1587MKII Multi-Channel Power Amplifier - Black



RMB-1587MKII

Rotel’s new RMB-1587MKII 7-channel amplifier furthers our heritage of producing high powered, high current, exceptionally manufactured Class AB amplifiers for multi-channel systems. The RMB-1587MKII delivers 7 channels of Class AB amplification at 155 Watts per channel into 8 ohms and drives 4 ohm speakers with over 250 Watts per channel, all channels driven.



Power7 x 250 Watts
of robust power, 4 Ohms

Class ABClass AB amplifier design

TransformerMassive power supply
using Dual Toroidal Transformers

CapacitorHigh quality slit foil capacitors

Rack MountRack ears included



DESCRIPTION:

Rotel’s new RMB-1587MKII 7-channel amplifier continues our heritage of producing high powered, perfectionist amplifiers for multi-channel systems.

Following Rotel's MKII design architecture, the RMB-1587MKII incorporates significant circuit and component upgrades in both the power supply and amplifier stages achieving ultra-low distortion, signal isolation, and high-gain output power efficiently packaged in a single, multi-channel amplifier chassis.

Differing from multi-channel amplifiers whose output drops when driving multiple channels simultaneously, the RMB-1587MKII delivers all 7 channels of Class AB amplification at 155 Watts per channel into 8 ohms, and 250 Watts per channel into 4 ohms with all channels driven.



SPECIFICATIONS:

DIMENSIONS (W × H × D)
431 × 237 × 456mm
17" × 9.4" × 18"

FRONT PANEL HEIGHT
5U / 221mm (8.75")

POWER REQUIREMENTS
230V, 50Hz

POWER CONSUMPTION
1400W

NET WEIGHT
37.6kg (82.9lbs.)

BTU RATING (4Ω, 1/8th power)
4016 BTU/h

CONTINUOUS POWER OUTPUT
155W/Ch (7 channels driven, 8Ω)
250W/Ch (7 channels driven, 4Ω)
335W/Ch (2 channels driven, 4Ω)

TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%

FREQUENCY RESPONSE
10Hz - 100kHz +0, -3dB

S/N RATIO (IHF "A" Weighted)
111dB

GAIN
26.6dB

CROSSTALK/SEPARATION
> 55dB

INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%

DAMPING FACTOR
330


INPUT SENSITIVITY
Line Level Inputs (RCA): 1.61V
Line Level Inputs (XLR): 3.4V

INPUT IMPEDANCE
Line Level Inputs (RCA): 12kΩ
Line Level Inputs (XLR): 50kΩ
